1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer

1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer

PWD-13-50-PA66-BK

$1.40
$1.40
Sale Sold out
Shipping calculated at checkout.

9170 in stock
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

281 7171145
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.com
Scroll
Type
Clamp Dia In (fr) ?

Clamp Dia In (fr): The clamp's internal diameter listed as a fractional measurement in inches (e.g., 1, 1/2 in.).
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
Band Thk ?

Band Thickness (in/mm): Indicates the physical thickness (height or depth) of the band, measured in inches or Millimetres.

HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
2D PDF ?

2D PDF: A standard document format containing two-dimensional drawings.
2D DXF ?

2D DXF: A standard file format for exchanging two-dimensional Computer-Aided Design (CAD) drawings between different software programs.
3D STP ?

3D STEP: A standard file format used to exchange three-dimensional product model data between different CAD software programs.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		STRAP PART - 1 in - 2 in - 0.98in - 1.97in - 25.0mm - 50.0mm - 1/2 in (12.7mm) - 1/8 in (3.25mm) - PWD-13-50-PA12-BK - - - - $1.40 9170
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		STRAP PART - 1 in - 3 in - 0.98in - 2.95in - 25.0mm - 75.0mm - 1/2 in (12.7mm) - 1/8 in (3.25mm) - PWD-13-75-PA66-BK - - - - $1.70 7089
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		STRAP PART - 1 in - 4 in - 0.98in - 3.94in - 25.0mm - 100.0mm - 1/2 in (12.7mm) - 1/8 in (3.25mm) - PWD-13-100-PA66-BK - - - - $2.24 6711
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		STRAP PART - 2 in - 5 in - 1.97in - 4.92in - 50.0mm - 125.0mm - 1/2 in (12.7mm) - 1/8 in (3.25mm) - PWD-13-125-PA66-BK - - - - $2.50 2594
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		STRAP PART - 3 in - 6 in - 2.95in - 5.91in - 75/0mm - 150.0mm - 1/2 in (12.7mm) - 1/8 in (3.25mm) - PWD-13-150-PA66-BK - - - - $3.11 3334
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		HEX SCREW - Size 5/16" (8.0mm) A/F - - - Buy with Strap Part - - - PWD-SC-PA66-BK - - - - $0.43 372
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
1/2" Ezyclamp PA66 Plastic Worm Drive Hex Screw Hose Clamp - Black Polymer
- 		WING SCREW - Turn-Key Screw - - - Buy with Strap Part - - - PWD-WG-PA66-BK - - - - $0.67 4461

Description

Designed and manufactured by HCL to the highest quality the Ezyclamp™ is a highly versatile Nylon Worm Drive Hose Clamp. The Ezyclamp™ is 12.7mm (½”) wide and available in 5 sizes covering a diameter range of 25mm (1”) to 150mm (6”). It is offered in a choice of materials: PA66 (Nylon 6.6.) for standard and higher temperature applications & PA12 (Nylon 12) with increased UV resistance for niche markets such as 5G telecommunications & Subsea.

NOTE: Screw and Strap are sold separately - both are required for installation

Product Specification Sheet

Download

Specification

Manufactured By HCL
HCL P/N PWD-X-PA66-BK
Series HCL Ezyclamp
Corrosion Resistance Excellent
Hose Clamp Width in/mm 1/2 in (12.7mm)
Band Style Embossed Band
Band Material Nylon 6.6 (PA66)
Bolt/Screw Type Hex Nut
Bolt/Screw Material Nylon 6.6 (PA66)
Bolt/Screw Size 5/16 in (8.0mm) A/F
Max Peak Operating Temp 302°F - 150°C
Recommended Installation Temp 60°F - 140°C
Continuous Use Temperature 257°F - 125°C
Flammability UL 94 V-2
Chemical Resistance Very Good
Colour Black
Recommended Torque Nm 2.0 Nm
Country of Manufacture United Kingdom
Tariff Code 3917 40 00 99
Hazardous Goods No
RoHS Compliant Yes

Robust & Non-Corrosive: Ezyclamp Plastic Worm Drive Hose Clamp - ½" Wide Black Polymer (25.0-150.0mm)

Experience exceptional chemical and temperature resistance with the PA66 Ezyclamp Plastic Worm Drive Hose Clamp. Constructed from durable black Nylon 6.6 polymer, this non-metallic clamp offers a robust yet lightweight solution for a wide range of applications where traditional metal clamps are unsuitable. The ½" wide band provides secure clamping across a size range of 25.0mm to 150.0mm (0.98-5.90in), and the choice of screws 8mm hex or wing allows for controlled tightening with standard tools or by hand

Why Choose the PA66 Ezyclamp Plastic Worm Drive Hose Clamp?

  • Complete Non-Metallic Polymer Construction: Eliminates corrosion, rust, and electrolysis, ideal for marine, chemical, and other demanding environments.
  • Chemically Resistant Black Polymer: Withstands a wide range of chemicals and harsh substances.
  • ½" Wide Band for Secure Clamping: Provides a broad contact surface for effective and even pressure distribution.
  • Versatile Size Range: Accommodates hose diameters from 25.0mm to 150.0mm (0.98-5.90in).
  • Hex Screw for Controlled Tightening: Allows for precise torque application using standard wrenches or sockets.
  • Wing Screw Option: For hand tightening
  • Lightweight and Durable: Offers excellent strength and longevity without adding unnecessary weight.
  • Safe for Sensitive Materials: The smooth polymer construction helps prevent damage to delicate hoses.
  • PA66 material: Known for its toughness and higher temperature resistance

Perfect For:

  • Marine and Boat Plumbing (above and below waterline)
  • Chemical Processing and Transfer
  • Laboratory Equipment
  • Water Treatment Facilities
  • Food and Beverage Processing
  • Any application requiring complete corrosion and chemical resistance

Enjoy Reliable, Non-Metallic Clamping Power:

The Ezyclamp PA66 Plastic Worm Drive Hose Clamp provides a superior alternative to metal clamps in corrosive or chemically aggressive environments. Its full polymer construction ensures complete resistance to rust, electrolysis, and a wide array of chemicals. The ½" wide band delivers a strong and even clamping force, while the hex screw allows for controlled tightening to achieve a secure, leak-free seal. This clamp is the ideal choice for applications where durability and resistance to the elements are paramount.

Key Features:

  • Material: Black Polymer
  • Bandwidth: ½"
  • Size Range: 25.0mm-150.0mm (0.98-5.90in)
  • Type: Worm Drive Hose Clamp with Hex Screw
  • 100% Non-Metallic, Corrosion-Proof, and Chemical Resistant
  • Controlled Tightening with Hex Screw
  • Hand tighten with Wing Screw

For a robust, lightweight, and completely corrosion and chemical-resistant hose clamping solution, choose the Ezyclamp Plastic Worm Drive Hose Clamp. Browse our selection and secure your connections with confidence today!
