5/8” Ideal Tridon Pow’r-Gear Worm Gear Hose Clamp - 301SS Band & Screw

5/8” Ideal Tridon Pow’r-Gear Worm Gear Hose Clamp - 301SS Band & Screw

TRI-60-PWG-150

$2.45
$2.45
Sale Sold out
Shipping calculated at checkout.

Backorder
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

281 7171145
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.com
Scroll
Clamp Dia In (fr) ?

Clamp Dia In (fr): The clamp's internal diameter listed as a fractional measurement in inches (e.g., 1, 1/2 in.).
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
SAE No. ?

SAE No.: A number within a classification system established by SAE International
HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
MFG P/N ?

MFG P/N: The unique identifying number assigned to a part by its manufacturer.
Corrosion Res ?

Corrosion Resistance: Refers to a material's ability to resist deterioration or damage caused by chemical reactions with its environment, such as rusting.
2D PDF ?

2D PDF: A standard document format containing two-dimensional drawings.
2D DXF ?

2D DXF: A standard file format for exchanging two-dimensional Computer-Aided Design (CAD) drawings between different software programs.
3D STP ?

3D STEP: A standard file format used to exchange three-dimensional product model data between different CAD software programs.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

7/8 in - 1,1/2 in - 0.87in - 1.50in - 22.0mm - 38.0mm - 5/8 in (16.0mm) - 150 - TRI-60-PWG-150 - 60150 - Good - 2D PDF - 2D DXF - 3D STP - $2.45 0
1 in - 1,3/4 in - 0.98in - 1.73in - 25.0mm - 44.0mm - 5/8 in (16.0mm) - 175 - TRI-60-PWG-175 - 60175 - Good - 2D PDF - 2D DXF - 3D STP - $2.51 121
1,1/4 in - 2,1,8 in - 1.26in - 2.13in - 32.0mm - 54.0mm - 5/8 in (16.0mm) - 212 - TRI-60-PWG-212 - 60200 - Good - 2D PDF - 2D DXF - 3D STP - $2.59 264
1,3/4 in - 2,5/8 in - 1.77in - 2.60in - 45.0mm - 66.0mm - 5/8 in (16.0mm) - 262 - TRI-60-PWG-262 - 60250 - Good - 2D PDF - 2D DXF - 3D STP - $2.71 277
2,1/4 in - 3,1/8 in - 2.24in - 3.11in - 57.0mm - 79.0mm - 5/8 in (16.0mm) - 312 - TRI-60-PWG-312 - 60300 - Good - 2D PDF - 2D DXF - 3D STP - $2.87 3063
2,3/4 in - 3,5/8 in - 2.76in - 3.62in - 70.0mm - 92.0mm - 5/8 in (16.0mm) - 362 - TRI-60-PWG-362 - 60350 - Good - 2D PDF - 2D DXF - 3D STP - $2.99 178
3,1/4 in - 4,1/8 in - 3.27in - 4.09in - 83.0mm - 104.0mm - 5/8 in (16.0mm) - 412 - TRI-60-PWG-412 - 60400 - Good - 2D PDF - 2D DXF - 3D STP - $3.16 235
3,3/4 in - 4,5/8 in - 3.74in - 4.61in - 95.0mm - 117.0mm - 5/8 in (16.0mm) - 462 - TRI-60-PWG-462 - 60450 - Good - 2D PDF - 2D DXF - 3D STP - $3.22 31
4,1/4 in - 5,1/8 in - 4.25in - 5.12in - 108.0mm - 130.0mm - 5/8 in (16.0mm) - 512 - TRI-60-PWG-512 - 60500 - Good - 2D PDF - 2D DXF - 3D STP - $3.33 105
4,3/4 in - 5,5/8 in - 4.76in - 5.59in - 121.0mm - 142.0mm - 5/8 in (16.0mm) - 562 - TRI-60-PWG-562 - 60550 - Good - 2D PDF - 2D DXF - 3D STP - $3.48 141
5,1/4 in - 6,1/8 in - 5.24in - 6.10in - 133.0mm - 155.0mm - 5/8 in (16.0mm) - 612 - TRI-60-PWG-612 - 60600 - Good - 2D PDF - 2D DXF - 3D STP - $3.62 138
5,3/4 in - 6,5/8 in - 5.75in - 6.61in - 146.0mm - 168.0mm - 5/8 in (16.0mm) - 662 - TRI-60-PWG-662 - 60650 - Good - 2D PDF - 2D DXF - 3D STP - $3.76 85
6,1/4 in - 7,1/8 in - 6.26in - 7.13in - 159.0mm - 181.0mm - 5/8 in (16.0mm) - 712 - TRI-60-PWG-712 - 60700 - Good - 2D PDF - 2D DXF - 3D STP - $3.91 98
6,3/4 in - 7,5/8 in - 6.77in - 7.60in - 172.0mm - 193.0mm - 5/8 in (16.0mm) - 762 - TRI-60-PWG-762 - 60750 - Good - 2D PDF - 2D DXF - 3D STP - $4.06 94
7,1/4 in - 8,1/8 in - 7.24in - 8.11in - 184.0mm - 206.0mm - 5/8 in (16.0mm) - 812 - TRI-60-PWG-812 - 60800 - Good - 2D PDF - 2D DXF - 3D STP - $4.85 96
7,3/4 in - 8,5/8 in - 7.76in - 8.62in - 197.0mm - 219.0mm - 5/8 in (16.0mm) - 862 - TRI-60-PWG-862 - 60850 - Good - 2D PDF - 2D DXF - 3D STP - $5.08 48
8,1/4 in - 9,1/8 in - 8.27in - 9.09in - 210.0mm - 231.0mm - 5/8 in (16.0mm) - 912 - TRI-60-PWG-912 - 60900 - Good - 2D PDF - 2D DXF - 3D STP - $5.25 75

Description

5/8 inch (16mm) wide Pow’r-Gear 60 Series high performance clamps are designed for high vibration and stubborn leakage applications such as industrial machinery, heavy truck, farm and off-road equipment engines. Pow'r-Gear features an extra wide 5/8" heavy gauge band and a wide profile housing that provides maximum engagement of screw threads to band. Engineered to deliver exceptionally high rates of band tension to handle the toughest sealing jobs. The 304SS Band and 410SS Screw offer good corrosion resistance

Product Specification Sheet

Download

Specification

Manufactured By Ideal Tridon
HCL P/N TRI-60-PWG-X
Series Ideal Tridon Pow'r-Gear
Corrosion Resistance Good
Hose Clamp Width in/mm 5/8 in (16.0mm)
Band Style Perforated Band
Band Material 304 Stainless Steel
Housing Material 304 Stainless Steel
Bolt/Screw Type Slotted Hex
Bolt/Screw Material 410 Stainless Steel
Bolt/Screw Size 5/16" Hex Head
Chemical Resistance Good
Colour Silver
Tightening Torque 75-90 lbf-in (8.5-10 Nm) for most applications
Specification 1 SAE J1508
Country of Manufacture USA
Tariff Code 7326 90 92
Hazardous Goods No
RoHS Compliant Yes

Achieve secure and versatile clamping across a broad range of diameters with the Ideal Tridon 5/16" Worm Gear Hose Clamp. Featuring a durable 301 stainless steel band and screw, this clamp is designed for
reliability and corrosion resistance, handling everything from medium to larger diameter hoses and pipes.

Why Choose Ideal Tridon 5/16" 301SS Wide-Range Hose Clamps?

  • Extended Clamping Range: With an impressive adjustment range of 25mm to 232mm (1.0 to 9.13 inches), this clamp adapts to a variety of applications, reducing the need for multiple clamp sizes.
  • Durable 301 Stainless Steel: Both the band and screw are crafted from high-quality 301 stainless steel, providing a robust and corrosion-resistant solution.
  • 5/16" Band Versatility: The 5/16" band width offers a balance of strength and flexibility, suitable for a wide array of clamping tasks.
  • Trusted Ideal Tridon Quality: Rely on the established reputation of Ideal Tridon for consistent quality and reliable performance.
  • Multipurpose Functionality: Ideal for automotive, industrial, HVAC, and general-purpose applications requiring a wide clamping range.

Key Features:

  • Material: 301 Stainless Steel (Band & Screw)
  • Size: 5/16" Worm Gear Hose Clamp
  • Clamping Range: 25mm - 232mm (1.0in - 9.13in)
  • Wide Adjustment Range
  • Durable 301SS Construction
  • Ideal Tridon Reliability

Ideal Applications:

  • Large Diameter Automotive Hoses
  • Industrial Ducting and Piping
  • HVAC System Connections
  • Agricultural Equipment
  • General Large-Scale Fastening

Handle larger clamping needs with the dependable Ideal Tridon 5/16" Worm Gear Hose Clamp. The wide clamping range and durable 301SS construction provide a secure and lasting hold. Order your Ideal Tridon clamps today for versatile and reliable performance.
