Sale
  • Worm Gear Hose Clamp 1/2" Tridon Hy-Gear 300SS 7/16"-1,1/16" - HCL Clamping USA- TRI-67-4-HG-8
  • Worm Gear Hose Clamp 1/2" Tridon Hy-Gear 300SS 7/16"-1,1/16" - HCL Clamping USA- TRI-67-4-HG-8
  • Worm Gear Hose Clamp 1/2" Tridon Hy-Gear 300SS 7,1/4"-9,1/4" - HCL Clamping USA- TRI-67-4-HG-140
  • Worm Gear Hose Clamp 1/2" Tridon Hy-Gear 300SS 7,1/4"-9,1/4" - HCL Clamping USA- TRI-67-4-HG-140
1 4

1/2" Perforated Ideal Tridon Hy-Gear 67-4 Worm Gear Hose Clamp: 300SS Band & Screw

1/2" Perforated Ideal Tridon Hy-Gear 67-4 Worm Gear Hose Clamp: 300SS Band & Screw

TRI-67-4-HG-6

$1.24
$1.24
Sale Sold out
Shipping calculated at checkout.

335 in stock
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

281 7171145
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.com
Scroll
Clamp Dia In (fr) ?

Clamp Dia In (fr): The clamp's internal diameter listed as a fractional measurement in inches (e.g., 1, 1/2 in.).
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
SAE No. ?

SAE No.: A number within a classification system established by SAE International
HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
MFG P/N ?

MFG P/N: The unique identifying number assigned to a part by its manufacturer.
2D PDF ?

2D PDF: A standard document format containing two-dimensional drawings.
2D DXF ?

2D DXF: A standard file format for exchanging two-dimensional Computer-Aided Design (CAD) drawings between different software programs.
3D STP ?

3D STEP: A standard file format used to exchange three-dimensional product model data between different CAD software programs.
Corrosion Res ?

Corrosion Resistance: Refers to a material's ability to resist deterioration or damage caused by chemical reactions with its environment, such as rusting.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

3/8 in−7/8 in - 0.39in - 0.87in - 10.0mm - 22.0mm - 1/2 in (12.7mm) - 6 - TRI-67-4-HG-6 - 67004-0006 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.24 335
7/16 in − 1 in - 0.43in - 0.98in - 11.0mm - 25.0mm - 1/2 in (12.7mm) - 8 - TRI-67-4-HG-8 - 67004-0008 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.26 66
1/2 in − 1,1/16 in - 0.51in - 1.06in - 13.0mm - 27.0mm - 1/2 in (12.7mm) - 10 - TRI-67-4-HG-10 - 67004-0010 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.30 804
1/2 in − 1,1/4 in - 0.51in - 1.26in - 13.0mm - 32.0mm - 1/2 in (12.7mm) - 12 - TRI-67-4-HG-12 - 67004-0012 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.32 549
11/16 in − 1,1/2 in - 0.71in - 1.50in - 18.0mm - 38.0mm - 1/2 in (12.7mm) - 16 - TRI-67-4-HG-16 - 67004-0016 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.36 1281
3/4 in − 1,3/4 in - 0.75in - 1.73in - 19.0mm - 44.0mm - 1/2 in (12.7mm) - 20 - TRI-67-4-HG-20 - 67004-0020 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.45 288
1 in − 2 in - 1.02in - 2.01in - 26.0mm - 51.0mm - 1/2 in (12.7mm) - 24 - TRI-67-4-HG-24 - 67004-0024 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.49 467
1,1/4 in − 2,1/4 in - 1.26in - 2.24in - 32.0mm - 57.0mm - 1/2 in (12.7mm) - 28 - TRI-67-4-HG-28 - 67004-0028 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.53 500
1,1/2 in − 2,1/2 in - 1.50in - 2.48in - 38.0mm - 63.0mm - 1/2 in (12.7mm) - 32 - TRI-67-4-HG-32 - 67004-0032 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.58 869
3/4 in − 2,3/4 in - 0.75in - 2.76in - 19.0mm - 70.0mm - 1/2 in (12.7mm) - 36 - TRI-67-4-HG-36 - 67004-0036 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.64 157
1 in − 3 in - 1.02in - 2.99in - 26.0mm - 76.0mm - 1/2 in (12.7mm) - 40 - TRI-67-4-HG-40 - 67004-0040 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.73 213
1,1/4 in − 3,1/4 in - 1.26in - 3.23in - 32.0mm - 82.0mm - 1/2 in (12.7mm) - 44 - TRI-67-4-HG-44 - 67004-0044 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.61 0
1,1/2 in − 3,1/2 in - 1.50in - 3.50in - 38.0mm - 89.0mm - 1/2 in (12.7mm) - 48 - TRI-67-4-HG-48 - 67004-0048 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.86 0
1,3/4 in − 3,3/4 in - 1.73in - 3.74in - 44.0mm - 95.0mm - 1/2 in (12.7mm) - 52 - TRI-67-4-HG-52 - 67004-0052 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.90 0
2 in − 4 in - 2.01in - 3.98in - 51.0mm - 101.0mm - 1/2 in (12.7mm) - 56 - TRI-67-4-HG-56 - 67004-0056 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.94 504
2,1/4 in − 4,1/4 in - 2.24in - 4.25in - 57.0mm - 108.0mm - 1/2 in (12.7mm) - 60 - TRI-67-4-HG-60 - 67004-0060 - 2D PDF - 2D DXF - 3D STP - Very Good - $1.97 134
2,1/2 in − 4,1/2 in - 2.52in - 4.49in - 64.0mm - 114.0mm - 1/2 in (12.7mm) - 64 - TRI-67-4-HG-64 - 67004-0064 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.01 444
3 in − 5 in - 2.99in - 5.00in - 76.0mm - 127.0mm - 1/2 in (12.7mm) - 72 - TRI-67-4-HG-72 - 67004-0072 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.11 194
3,1/2 in − 5,1/2 in - 3.50in - 5.51in - 89.0mm - 140.0mm - 1/2 in (12.7mm) - 80 - TRI-67-4-HG-80 - 67004-0080 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.48 109
4 in − 6 in - 4.02in - 5.98in - 102.0mm - 152.0mm - 1/2 in (12.7mm) - 88 - TRI-67-4-HG-88 - 67004-0088 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.51 786
4,1/2 in − 6,1/2 in - 4.49in - 6.50in - 114.0mm - 165.0mm - 1/2 in (12.7mm) - 96 - TRI-67-4-HG-96 - 67004-0096 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.65 194
5 in − 7 in - 5.00in - 7.01in - 127.0mm - 178.0mm - 1/2 in (12.7mm) - 104 - TRI-67-4-HG-104 - 67004-0104 - 2D PDF - 2D DXF - 3D STP - Very Good - $2.72 18
2 in − 10 in - 2.01in - 10.00in - 51.0mm - 254.0mm - 1/2 in (12.7mm) - 152 - TRI-67-4-HG-152 - 67004-0152 - 2D PDF - 2D DXF - 3D STP - Very Good - $3.52 0

Description

1/2" (12.7mm) wide Hy-Gear worm gear hose clamps are suitable for most common household, industrial, and automotive applications. The bands have clean punched rectangular perforations that hold strong and connect easily. The 67-4 series is made from 300 Stainless Steel offering very good corrosion resistant properties

Product Specification Sheet

Download

Specification

Manufactured By Ideal Tridon
HCL P/N TRI-67-4-HG-X
Series Ideal Tridon Hy-Gear
Corrosion Resistance Very Good
Hose Clamp Width in/mm 1/2 in (12.7mm)
Band Style Perforated Band
Band Material 301 Stainless Steel
Housing Material 301 Stainless Steel
Bolt/Screw Type Slotted Hex
Bolt/Screw Material 305 Stainless Steel
Bolt/Screw Size 5/16" Hex Head
Chemical Resistance Very Good
Colour Silver
Tightening Torque 35 lbf-in (4 Nm) for most applications
Specification 1 SAE J1508
Country of Manufacture USA
Tariff Code 7326 90 92
RoHS Compliant Yes

Ideal Tridon 1/2" Stainless Steel Hose Clamp: 301SS
Band, 305SS Screw - High Strength & Corrosion Resistance (11mm-178mm)

Experience the perfect blend of strength and corrosion
resistance with the Ideal Tridon 1/2" Stainless Steel Hose Clamp. Featuring a robust 301 stainless steel band and a corrosion-resistant 305 stainless steel screw, this clamp is designed for reliable performance in a wide array of demanding applications.

Why Choose Ideal Tridon 301/305SS Hose Clamps?

  • Optimized Material Combination: The 301SS band provides exceptional tensile strength and flexibility, ensuring a secure and tight seal. The 305SS screw enhances corrosion resistance, offering superior durability in challenging environments.
  • High-Strength Performance: The combination of these premium stainless steel grades delivers a clamp that can withstand high pressures and maintain its integrity over time.
  • Wide Adjustment Range: With an adjustable range of 11mm to 178mm (0.43 to 7.01 inches), this 1/2" hose clamp is versatile enough to fit a variety of hose and pipe sizes.
  • Reliable Ideal Tridon Quality: Trust in the established quality of Ideal Tridon, a leader in clamping solutions, for consistent and dependable performance.
  • Versatile Applications: Ideal for automotive, industrial, plumbing, and general-purpose applications where strength and corrosion resistance are essential.

Key Features:

  • Screw Material: 305 Stainless Steel
  • Band Material: 301 Stainless Steel
  • Size: 1/2" Hose Clamp
  • Clamping Range: 11mm - 178mm (0.43in - 7.01in)
  • High-Strength 301SS Band
  • Corrosion-Resistant 305SS Screw
  • Trusted Ideal Tridon Brand

Ideal Applications:

  • Automotive Hose Connections
  • Industrial Fluid Handling
  • Plumbing and HVAC Systems
  • General Purpose Fastening
  • Applications needing a strong clamp with good corrosion resistance.

Secure your connections with the dependable Ideal Tridon 1/2" Stainless Steel Hose Clamp. The 301SS band and 305SS screw combination provides the strength and corrosion resistance you need. Order your Ideal Tridon clamps today for a reliable, long-lasting solution.
