1/2" Perforated Ideal Tridon Hy-Gear 67-6 Worm Gear Hose Clamp: Full 316SS Marine-Grade

1/2" Perforated Ideal Tridon Hy-Gear 67-6 Worm Gear Hose Clamp: Full 316SS Marine-Grade

TRI-67-6-HG-6

$1.70
$1.70
Sale Sold out
Shipping calculated at checkout.

210 in stock
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

281 7171145
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.com
Scroll
Clamp Dia In (fr) ?

Clamp Dia In (fr): The clamp's internal diameter listed as a fractional measurement in inches (e.g., 1, 1/2 in.).
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
SAE No. ?

SAE No.: A number within a classification system established by SAE International
HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
MFG P/N ?

MFG P/N: The unique identifying number assigned to a part by its manufacturer.
2D PDF ?

2D PDF: A standard document format containing two-dimensional drawings.
2D DXF ?

2D DXF: A standard file format for exchanging two-dimensional Computer-Aided Design (CAD) drawings between different software programs.
3D STP ?

3D STEP: A standard file format used to exchange three-dimensional product model data between different CAD software programs.
Corrosion Res ?

Corrosion Resistance: Refers to a material's ability to resist deterioration or damage caused by chemical reactions with its environment, such as rusting.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

3/8 in−7/8 in - 0.39in - 0.87in - 10.0mm - 22.0mm - 1/2 in (12.7mm) - 6 - TRI-67-6-HG-6 - 6706-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.70 210
7/16 in − 1 in - 0.43in - 0.98in - 11.0mm - 25.0mm - 1/2 in (12.7mm) - 8 - TRI-67-6-HG-8 - 6708-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.73 436
1/2 in − 1,1/16 in - 0.51in - 1.06in - 13.0mm - 27.0mm - 1/2 in (12.7mm) - 10 - TRI-67-6-HG-10 - 6710-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.78 233
1/2 in − 1,1/4 in - 0.51in - 1.26in - 13.0mm - 32.0mm - 1/2 in (12.7mm) - 12 - TRI-67-6-HG-12 - 6712-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.80 316
11/16 in − 1,1/2 in - 0.71in - 1.50in - 18.0mm - 38.0mm - 1/2 in (12.7mm) - 16 - TRI-67-6-HG-16 - 6716-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.90 1003
3/4 in − 1,3/4 in - 0.75in - 1.73in - 19.0mm - 44.0mm - 1/2 in (12.7mm) - 20 - TRI-67-6-HG-20 - 6720-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $1.99 247
1 in − 2 in - 1.02in - 2.01in - 26.0mm - 51.0mm - 1/2 in (12.7mm) - 24 - TRI-67-6-HG-24 - 6724-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.06 244
1,1/4 in − 2,1/4 in - 1.26in - 2.24in - 32.0mm - 57.0mm - 1/2 in (12.7mm) - 28 - TRI-67-6-HG-28 - 6728-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.13 464
1,1/2 in − 2,1/2 in - 1.50in - 2.48in - 38.0mm - 63.0mm - 1/2 in (12.7mm) - 32 - TRI-67-6-HG-32 - 6732-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.22 1887
3/4 in − 2,3/4 in - 0.75in - 2.76in - 19.0mm - 70.0mm - 1/2 in (12.7mm) - 36 - TRI-67-6-HG-36 - 6736-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.31 2665
1 in − 3 in - 1.02in - 2.99in - 26.0mm - 76.0mm - 1/2 in (12.7mm) - 40 - TRI-67-6-HG-40 - 6740-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.43 782
1,1/4 in − 3,1/4 in - 1.26in - 3.23in - 32.0mm - 82.0mm - 1/2 in (12.7mm) - 44 - TRI-67-6-HG-44 - 6744-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.33 10540
1,1/2 in − 3,1/2 in - 1.50in - 3.50in - 38.0mm - 89.0mm - 1/2 in (12.7mm) - 48 - TRI-67-6-HG-48 - 6748-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.63 463
1,3/4 in − 3,3/4 in - 1.73in - 3.74in - 44.0mm - 95.0mm - 1/2 in (12.7mm) - 52 - TRI-67-6-HG-52 - 6752-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.71 250
2 in − 4 in - 2.01in - 3.98in - 51.0mm - 101.0mm - 1/2 in (12.7mm) - 56 - TRI-67-6-HG-56 - 6756-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.77 3500
2,1/4 in − 4,1/4 in - 2.24in - 4.25in - 57.0mm - 108.0mm - 1/2 in (12.7mm) - 60 - TRI-67-6-HG-60 - 6760-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.84 226
2,1/2 in − 4,1/2 in - 2.52in - 4.49in - 64.0mm - 114.0mm - 1/2 in (12.7mm) - 64 - TRI-67-6-HG-64 - 6764-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $2.90 245
3 in − 5 in - 2.99in - 5.00in - 76.0mm - 127.0mm - 1/2 in (12.7mm) - 72 - TRI-67-6-HG-72 - 6772-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $3.08 700
3,1/2 in − 5,1/2 in - 3.50in - 5.51in - 89.0mm - 140.0mm - 1/2 in (12.7mm) - 80 - TRI-67-6-HG-80 - 6780-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $3.54 147
4 in − 6 in - 4.02in - 5.98in - 102.0mm - 152.0mm - 1/2 in (12.7mm) - 88 - TRI-67-6-HG-88 - 6788-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $3.74 150
4,1/2 in − 6,1/2 in - 4.49in - 6.50in - 114.0mm - 165.0mm - 1/2 in (12.7mm) - 96 - TRI-67-6-HG-96 - 6796-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $3.83 130
5 in - 7 in - 5.00in - 7.01in - 127.0mm - 178.0mm - 1/2 in (12.7mm( - 104 - TRI-67-6-HG-104 - 6799-6 - 2D PDF - 2D DXF - 3D STP - Excellent - $4.42 0

Description

1/2" Hy-Gear clamps are suitable for most common household, industrial, and automotive applications. The bands have clean punched rectangular perforations that hold strong and connect easily. The full 316SS material makes this clamp perfect for marine application.

Product Specification Sheet

Download

Specification

Manufactured By Ideal Tridon
HCL P/N TRI-67-6-HG-X
Series Ideal Tridon Hy-Gear
Corrosion Resistance Excellent
Hose Clamp Width in/mm 1/2 in (12.7mm)
Band Style Perforated Band
Band Material 316 Stainless Steel
Housing Material 316 Stainless Steel
Bolt/Screw Type Slotted Hex
Bolt/Screw Material 316 Stainless Steel
Bolt/Screw Size 5/16" Hex Head
Chemical Resistance Excellent
Colour Silver
Tightening Torque 35 lbf-in (4 Nm) for most applications
Specification 1 SAE J1508
Country of Manufacture USA
Tariff Code 7326 90 92
RoHS Compliant Yes

Ideal Tridon 1/2" 316SS Marine-Grade Worm Gear Hose Clamp: Ultimate Corrosion Resistance (11mm-178mm)

For the absolute pinnacle of corrosion resistance and
enduring performance, choose the Ideal Tridon 1/2" Worm Gear Hose Clamp. Crafted entirely from premium 316 stainless steel, this marine-grade hose clamp is engineered to withstand the harshest environments, making it ideal for saltwater, chemical, and extreme temperature applications.

Why Choose Ideal Tridon 316SS Marine-Grade Hose Clamps?

  • Full 316 Stainless Steel Construction: Every component, from the band to the screw, is manufactured from 316 stainless steel, offering maximum resistance to rust, pitting, and crevice corrosion, especially in chloride-rich environments.
  • Marine-Grade Reliability: Designed for demanding marine applications, this clamp delivers unmatched durability and performance in saltwater and other corrosive conditions.
  • Wide Adjustable Range: Featuring a versatile clamping range of 11mm to 178mm (0.43 to 7.01 inches), this 1/2" worm gear hose clamp provides a secure and precise fit for a variety of hose and pipe sizes.
  • Superior Strength & Durability: The robust construction and precision engineering of Ideal Tridon clamps ensure a reliable and long-lasting connection
  • Versatile Applications: Ideal for marine, chemical processing, industrial, and any application requiring exceptional corrosion resistance.

Key Features:

  • Material: Full 316 Stainless Steel (Band & Screw)
  • Size: 1/2" Worm Gear Hose Clamp
  • Clamping Range: 11mm - 178mm (0.43in - 7.01in)
  • Marine-Grade Construction
  • Maximum Corrosion Resistance
  • High Strength and Durability

Perfect for:

  • Marine Plumbing and Systems
  • Saltwater Applications
  • Chemical Processing
  • Food and Beverage Industry
  • High-Corrosion Environments

Invest in the unmatched corrosion resistance and reliability of the Ideal Tridon 1/2" 316SS Marine-Grade Worm Gear Hose Clamp. Ensure secure and lasting connections in even the most challenging conditions. Order your Ideal Tridon 316SS clamps today.
