HCL 3/8 Inch Mini Screw Hose Clamp - Galvanised Steel Band and Screw

HCL 3/8 Inch Mini Screw Hose Clamp - Galvanised Steel Band and Screw

MC-7-W1

$0.35
$0.35
Sale Sold out
Shipping calculated at checkout.

2380 in stock
  • Free standard shipping. Next day delivery available. Find out more
View full details

Need advice? Talk to our expert customer support team

Call

281 7171145
Monday-Friday 8am to 4pm

Email

sales@hcl-clamping.com
Scroll
Clamp Dia In (fr) ?

Clamp Dia In (fr): The clamp's internal diameter listed as a fractional measurement in inches (e.g., 1, 1/2 in.).
Clamp Dia In ?

Clamp Dia In: The minimum to maximum inner diameter (in.) the clamp can securely cover, defining its usable size range.
Clamp Dia mm ?

Clamp Dia mm: The required metric size for a secure fit, indicating the outer diameter (in mm) of the component the clamp is meant to hold.
Band Width ?

Band Width: The measurement of the clamp's band or strap, indicating its width (often in mm or inches) and how much surface area it covers.
HCL P/N ?

HCL/ PN: The unique identifying number assigned to a part by HCL
Material ?

Material: The core substance used to manufacture the product (e.g., steel, plastic, rubber). Affects durability and performance.
Corrosion Res ?

Corrosion Resistance: Refers to a material's ability to resist deterioration or damage caused by chemical reactions with its environment, such as rusting.
Price ?

Price: The cost per unit

Stock ?

Stock: available products that can be purchased

Order Qty ?

Order Quantity: The total amount of units you wish to order

15/64 in - 5/16 in - 0.24in - 0.31in - 6.0mm - 8.0mm - 3/8 in (9.0mm) - MC-7-W1 - Galvanised (W1) - Fair - $0.35 2380
9/32 in - 23/64 in - 0.28in - 0.35in - 7.0mm - 9.0mm - 3/8 in (9.0mm) - MC-8-W1 - Galvanised (W1) - Fair - $0.38 0
5/16 in - 25/64 in - 0.31in - 0.39in - 8.0mm - 10.0mm - 3/8 in (9.0mm) - MC-9-W1 - Galvanised (W1) - Fair - $0.41 0
23/64 in - 7/16 in - 0.35in - 0.43in - 9.0mm - 11.0mm - 3/8 in (9.0mm) - MC-10-W1 - Galvanised (W1) - Fair - $0.44 4006
25/64 in - 15/32 in - 0.39in - 0.47in - 10.0mm - 12.0mm - 3/8 in (9.0mm) - MC-11-W1 - Galvanised (W1) - Fair - $0.46 595
7/16 in - 33/64 in - 0.43in - 0.51in - 11.0mm - 13.0mm - 3/8 in (9.0mm) - MC-12-W1 - Galvanised (W1) - Fair - $0.49 2567
15/32 in - 35/64 in - 0.47in - 0.55in - 12.0mm - 14.0mm - 3/8 in (9.0mm) - MC-13-W1 - Galvanised (W1) - Fair - $0.52 2019
33/64 in - 19/32 in - 0.51in - 0.59in - 13.0mm - 15.0mm - 3/8 in (9.0mm) - MC-14-W1 - Galvanised (W1) - Fair - $0.54 0
35/64 in - 5/8 in - 0.55in - 0.63in - 14.0mm - 16.0mm - 3/8 in (9.0mm) - MC-15-W1 - Galvanised (W1) - Fair - $0.57 940
19/32 in - 43/64 in - 0.59in - 0.67in - 15.0mm - 17.0mm - 3/8 in (9.0mm) - MC-16-W1 - Galvanised (W1) - Fair - $0.60 1594
5/8 in - 45/64 in - 0.63in - 0.71in - 16.0mm - 18.0mm - 3/8 in (9.0mm) - MC-17-W1 - Galvanised (W1) - Fair - $0.63 945
43/64 in - 3/4 in - 0.67in - 0.75in - 17.0mm - 19.0mm - 3/8 in (9.0mm) - MC-18-W1 - Galvanised (W1) - Fair - $0.65 692
45/64 in - 25/32 in - 0.71in - 0.79in - 18.0mm - 20.0mm - 3/8 in (9.0mm) - MC-19-W1 - Galvanised (W1) - Fair - $0.68 674
3/4-53/64 in - 0.75in - 0.83in - 19.0mm - 21.0mm - 3/8 in (9.0mm) - MC-20-W1 - Galvanised (W1) - Fair - $0.71 0
25/32 in - 55/64 in - 0.79in - 0.87in - 20.0mm - 22.0mm - 3/8 in (9.0mm) - MC-21-W1 - Galvanised (W1) - Fair - $0.73 173
53/64 in - 29/32 in - 0.83in - 0.91in - 21.0mm - 23.0mm - 3/8 in (9.0mm) - MC-22-W1 - Galvanised (W1) - Fair - $0.76 501
55/64 in - 15/16 in - 0.87in - 0.94in - 22.0mm - 24.0mm - 3/8 in (9.0mm) - MC-23-W1 - Galvanised (W1) - Fair - $0.79 135
29/32 in - 63/64 in - 0.91in - 0.98in - 23.0mm - 25.0mm - 3/8 in (9.0mm) - MC-24-W1 - Galvanised (W1) - Fair - $0.82 742
15/16 in - 1,1/32 in - 0.94in - 1.02in - 24.0mm - 26.0mm - 3/8 in (9.0mm) - MC-25-W1 - Galvanised (W1) - Fair - $0.84 95
63/64 in - 1,1/16 in - 0.98in - 1.06in - 25.0mm - 27.0mm - 3/8 in (9.0mm) - MC-26-W1 - Galvanised (W1) - Fair - $0.87 462
1,1/32 in - 1,7/64 in - 1.02in - 1.10in - 26.0mm - 28.0mm - 3/8 in (9.0mm) - MC-27-W1 - Galvanised (W1) - Fair - $0.90 223
1,1/16 in - 1,9/64 in - 1.06in - 1.14in - 27.0mm - 29.0mm - 3/8 in (9.0mm) - MC-28-W1 - Galvanised (W1) - Fair - $0.92 305
1,7/64 in - 1,3/16 in - 1.10in - 1.18in - 28.0mm - 30.0mm - 3/8 in (9.0mm) - MC-29-W1 - Galvanised (W1) - Fair - $0.95 411
1,9/64 in - 1,7/32 in - 1.14in - 1.22in - 29.0mm - 31.0mm - 3/8 in (9.0mm) - MC-30-W1 - Galvanised (W1) - Fair - $0.98 173

Description

HCL's Mini Screw Hose clamps, Nut & Bolt, Petrol Pipe or Fuel line Clips are particularly suitable for soft hoses and small diameters. The clamp forms a complete circle and has smooth edges. These hose clamps are made from Zinc Plated Steel.

Product Specification Sheet

Download

Specification

Manufactured By HCL
HCL P/N MC-X-W1
Series Mini Screw Clip
Corrosion Resistance Fair
Hose Clamp Width in/mm 3/8 in (9.0mm)
Band Material Zinc Plated Steel
Bolt/Screw Type Slotted Hex
Bolt/Screw Material Zinc Plated Steel
Bolt/Screw Size 1/4 in (7.0mm) AF
Colour Silver
Country of Manufacture China
Tariff Code 7326.9
Hazardous Goods No
RoHS Compliant Yes

Compact & Reliable: HCL 3/8 Inch Mini Screw Hose Clamp - Galvanised Steel (6.0-31.0mm | 0.23-1.22 Inches)

Ensure secure and reliable connections in confined spaces with the HCL 3/8 Inch Mini Screw Hose Clamp. Constructed from durable galvanised steel, this compact clamp features a standard screw tightening mechanism and a narrow 3/8 Inch (9mm) band. It provides a dependable sealing solution for smaller diameter hoses and tubes across a versatile size range of 6.0 to 31.0mm (0.23 to 1.22 Inches).

Why Choose the HCL 3/8 Inch Mini Screw Hose Clamp?

  • Compact Size: The narrow 3/8 Inch band and small overall footprint make it ideal for tight spaces and smaller diameter hoses.
  • Reliable Screw Tightening: Allows for precise adjustment of clamping pressure to achieve a secure and leak-free seal.
  • Durable Galvanised Steel: Offers good strength and corrosion resistance for a variety of applications.
  • Versatile Size Range: Covers diameters from 6.0 to 31.0mm (0.23 to 1.22 Inches), suitable for numerous small hose and tubing applications.
  • Easy Installation: Can be easily installed and tightened with a standard screwdriver or nut driver.
  • Cost-Effective Solution: Provides a dependable clamping solution at an economical price.
  • Trusted HCL Quality: HCL is a reputable manufacturer known for producing reliable fastening solutions.

Perfect For:

  • Automotive Fuel Lines (small diameter)
  • Vacuum Lines
  • Low-Pressure Air Lines
  • Small Appliance Hoses
  • Instrumentation Tubing
  • General Purpose Clamping in Confined Areas

Experience Reliable Sealing in Tight Spaces:

The HCL 3/8 Inch Mini Screw Hose Clamp is designed to provide a secure and leak-free seal in applications where space is limited. Its compact size allows it to fit into tight areas, while the reliable screw tightening mechanism ensures that the clamping pressure can be precisely adjusted to suit the specific hose and application. The galvanised steel
construction offers good durability for general use.

Key Features:

  • Material: Galvanised Steel (Band and Screw)
  • Bandwidth: 3/8 Inch (9mm)
  • Size Range: 6.0-31.0mm (0.23-1.22 Inches)
  • Type: Mini Screw Hose Clamp - Fuel Line Clip - Petrol Pipe Clip
  • Compact Size for Tight Spaces
  • Reliable Screw Tightening Mechanism
  • Cost-Effective Solution

For secure and reliable connections in confined spaces with smaller diameter hoses and tubes, choose the HCL 3/8 Inch Mini Screw Hose Clamp. Order yours today for an efficient and economical clamping solution!
